Combining a variety of lever designs, convenient installation and the Arrow benchmark for dependability, the CL Series is perfect in most any space.
MPN: CL11-SC-05A
Finish: Antique Brass
Construction – Tubular chassis.
Backset – Universal latch is standard. Adjustable for both 2-3/8″ (60mm) or 2-3/4″ (70mm).
Latch – Brass front. Supplied standard with 1″ x 2-1/4″ (25mm x 57mm) square corner, 1″ x 2-1/4″ radius corner and 1-1/8″ x 2-1/4″ (29mm x 57mm) square corner latch fronts. Available with drive-in latches.
Strike – 1-5/8″ x 2-1/4″ (41mm x 57mm) full lip strike standard. Available with 1-1/8″ x 2-3/4″ (29mm x 70mm) T strike, or 1-1/4″ x 4-7/8″ (32mm x 124mm) ANSI strike.
Door Thickness – Fits 1-3/8″ to 1-3/4″ (35mm-44mm) doors standard.
Exposed Trim – Levers are zinc based and are plated to match finish requirements.
Mounting – Leversets are supplied with concealed screws on inside rose.
